Fill & Seal Machine:- Cannon 100 4S LPP
Fully automatic mechanically operated vertical pouch form, fill & seal machine to pack 'Viscous liquids' with exclusive design pneumatic piston filling system. Machine supported on heavy duty angular structure mounted on castor wheel wrapped with stainless steel cabinet all contact parts are in stainless steel.
Application: Ideal to suit viscous & non viscous liquids, Paste, Cream, tomato paste, Sauce, Jelly,Ginger garlic paste, fruit pulp, Lubricant, adhesive, Paints, Dismembers etc.
|
Technical Specifications
|
|
Feeding head
|
Pneumatic pistion filling system
|
|
Production speed
|
30-35 sachets / min
|
|
Packing range
|
50-150 ml/gm
|
|
Film Width
|
up to 210mm
|
|
Film Thickness
|
60 to 80 microns
|
|
Film Material
|
Any heat sealable laminated film.
|
|
Sealer heating system
|
Continues only
|
|
Filling Accuracy
|
+/- 3ml/gm.
|
|
Inner Core Dia. of Fil, Roll
|
70mm
|
|
Outer Dia of the film roll
|
up to 350 mm
|
|
Pouch Style
|
3 or 4 side seal pillow pouch
|
|
Pouch width
|
up to 105 mm.
|
|
Pouch Length
|
up to 145 mm
|
|
Power Consumption
|
1.2 kW/Hour
|
|
Peak Power
|
3kW
|
|
Air compressor
|
2Hp. 1 Phase, 230v,Ac 50Hz
|
|
Air consumption
|
4 CFM @ 20C
|
|
Compressed air pressure
|
6.5 kg/cm2
|
|
Power requirement
|
Single Phase, 230 V, 50Hz
|
|
Pouch Counter
|
Provided
|
|
Date printing Device
|
Optional
|
|
Machine Dimensions
|
1500(h) x 450(w) x 450 (Depth)
|
|
Net Weight
|
450 kgs (approx)
|
|
